Maclean MCE132 Microwave PIR Junction Box 5 - 15m 180º IP20
SKU: 41928
EAN: 5902211102168
Shipping from £4.62, VAT included.
Express 24h shipping
30-day returns
2-year warranty
In stock, ready to ship
Secure Payments
Microwave Motion Sensor Junction Box Mount
Microwave 5.8GHz PIR with light intensity detection for installation in junction boxes.
Wide range of applications and detection through doors, panes of glass or thin walls.
Can work throughout the whole day or only during evening and night hours.
Maximum Load: 1200W (incandescent bulb), 300W (Energy saving bulb)
Detection range up to 15m
Specifikace:
- Detection Range: 180°
- Detection Distance: 5-15m (adjustable)
- HFSystem: 5.8GHz CW radar,ISM band
- Transmission Power:<0.2mW
- Installing Height:1-1.8m
- Power Consumption:approx 0.9W
- Detection Motion Speed:0.6-1.5m/s
Power Sourcing: 220-240V/AC
Power Frequency: 50Hz
Ambient Light Trigger: <3-2000LUX (adjustable)
Shut Off Time Delay: Min.10sec±3sec // max.12min±1min
Rated Load:1200W (incandescent bulb), 300W (Energy saving bulb)
Microwave 5.8GHz PIR with light intensity detection for installation in junction boxes.
Wide range of applications and detection through doors, panes of glass or thin walls.
Can work throughout the whole day or only during evening and night hours.
Maximum Load: 1200W (incandescent bulb), 300W (Energy saving bulb)
Detection range up to 15m
Specifikace:
- Detection Range: 180°
- Detection Distance: 5-15m (adjustable)
- HFSystem: 5.8GHz CW radar,ISM band
- Transmission Power:<0.2mW
- Installing Height:1-1.8m
- Power Consumption:approx 0.9W
- Detection Motion Speed:0.6-1.5m/s
Power Sourcing: 220-240V/AC
Power Frequency: 50Hz
Ambient Light Trigger: <3-2000LUX (adjustable)
Shut Off Time Delay: Min.10sec±3sec // max.12min±1min
Rated Load:1200W (incandescent bulb), 300W (Energy saving bulb)
